SF-SE4
| Availability: | |
|---|---|
| Quantity: | |
Automatic Flat Ribbon Cable Cutting, Splitting, and Stripping Machine
This machine offers full automation for cutting, splitting, and stripping flat ribbon cables. Suitable for use in the electronics industry, appliances, motors, lamps, toys, automotive parts, and other fields requiring precise wire processing.
Features：
1. Computer Control: Operated via computer interface and key controls, ensuring precision and ease of use.
2. Adjustable Settings: Allows flexible configuration of wire length, cord top, wire tail, and stripping length within the supported range, boosting production efficiency and reducing labor costs.
3. Stable Performance: Built for accuracy and reliability, ensuring consistent results with minimal downtime.
4. Compact Design: Desktop-sized and cost-effective, ideal for space-saving and budget-conscious operations.
5. Pneumatic Splitting Device: Supports adjustable splitting lengths from 0-60mm, with customized splitting blades tailored to the ribbon cable's thickness.
This versatile machine streamlines flat ribbon cable processing, making it an essential tool for modern manufacturing needs.
| Model | SF-SP3 | SF-SE4 |
| Features | Cut & Strip & Pneumatic Split | Cut & Strip & Electric Split |
| Available Wire Width | 8-16mm | 8-16mm |
| Cutting Length | 1-99999mm | 1-99999mm |
| Cutting Length Tolerances | ±(0.002*L)mm | ±(0.002*L)mm |
| Stripping Length | 0-20mm | 0-20mm |
| Display Screen | Chinese / English LCD Screen | Chinese / English LCD Screen |
| Drive Method | 4 wheels drive | 4 wheels drive |
| Power Supply | 110/220VAC, 50/60Hz | 110/220VAC, 50/60Hz |
| Twisting Length | Can custom 4-15mm | Can custom 4-15mm |
| Production Rate | 2000-3300pcs/h | 2000-3300pcs/h |
| Power | 400W | 750W |
| Dimensions | 42*40*28cm | 42*40*28cm |
| Weight | 35kg | 37kg |
Application
The SF-SE4 is an automatic machine for cutting, splitting, and stripping flat ribbon cables. It is used in electronics, appliances, motors, lamps, toys, and automotive parts manufacturing, featuring electric splitting with a computer interface for precision control.
It processes flat cables with a width range of 8-16mm. It supports cutting lengths from 1-99999mm with a tolerance of ±(0.002*L)mm, stripping lengths of 0-20mm, and twisting length customizable from 4-15mm.
The SF-SE4 offers a production rate of 2000-3300 pieces per hour. Key features include electric splitting, a computer control interface, adjustable splitting length (0-60mm), and a 4-wheel drive system with a Chinese/English LCD screen.
Unique features include electric splitting with adjustable length (0-60mm) and customized splitting blades for different ribbon cable thicknesses. It also features computer-controlled precision, flexible length and stripping settings, and a compact desktop design.
The SF-SE4 requires 110/220VAC, 50/60Hz power (750W) and has dimensions of 42*40*28cm, weighing 37kg. It is a compact benchtop unit suitable for space-saving operations.
The computer interface and LCD screen allow easy adjustment of cutting length, stripping length, splitting length, and other parameters. Customized splitting blades can be tailored to specific ribbon cable thicknesses, and free sample testing is offered.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
