TA-S01
| Availability: | |
|---|---|
| Quantity: | |
This is a fully automatic single-press termination machine that supports one-side stripping and twisting, and the other-side stripping and crimping.
Features:
1. Supports a wide range of wire types for versatile applications.
2. Four-wheel feeding mechanism ensures high accuracy and stable wire feeding.
3. High-quality and high-precision components guarantee reliable final product quality.
4. User-friendly visualization touch screen reduces operational difficulty and improves efficiency.
5. Capable of storing processing parameters for different wires, enabling quick setup and repeatable operations.
| Model | TA-S01 | TA-S02 | TA-S03 |
| Features | Regular | Small wire | Big wire |
| Available Wire Size | AWG18-28# | AWG20-32# | AWG12-26# |
| Cutting Length | 45-999mm | 45-999mm | 45-999mm |
| Length Tolerance | ±0.2%*L | ±0.2%*L | ±0.2%*L |
| Stripping Length | 0-10mm | 0-10mm | 0-10mm |
| Detection Device | Lack wire detection, Lack terminal detection, Crimp detection, Pressure detection | ||
| Machine Production Rate | About 4000 pcs/h | About 4000 pcs/h | About 4000 pcs/h |
| Air Connection | 0.4-0.6MPa | 0.4-0.6MPa | 0.4-0.6MPa |
| Power Supply | 110/220VAC,50/60Hz | 110/220VAC,50/60Hz | 110/220VAC,50/60Hz |
| Power | 2100W | 2100W | 2100W |
| Weight | About 280kg | About 280kg | About 280kg |
| Dimensions | 120*60*200cm | 120*60*200cm | 120*60*200cm |
Application
Fully automatic one-ends wire cutting stripping and terminal crimping machine.
The TA-S01 is a fully automatic single-press termination machine that performs one-side stripping and twisting, and the other-side stripping and crimping in a single operation. It processes regular wires (AWG18-28#) with a production rate of about 4000 pieces per hour.
It processes AWG18-28# wires with cutting lengths from 45-999mm (tolerance ±0.2%*L) and stripping lengths of 0-10mm. It requires 0.4-0.6MPa air pressure and 110/220VAC, 50/60Hz power (2100W).
The machine is equipped with comprehensive detection including lack wire detection, lack terminal detection, crimp detection, and pressure detection, ensuring consistent quality and reducing defective products.
Key features include a four-wheel feeding mechanism for stable feeding, user-friendly touch screen for easy parameter setting, storage of processing parameters for quick changeovers, and support for one-side twisting with the other-side crimping in a single cycle.
The TA-S01 requires 110/220VAC, 50/60Hz power (2100W) and has dimensions of 120*60*200cm, weighing approximately 280kg. It is a floor-standing unit requiring dedicated floor space.
The touch screen allows easy adjustment of cutting length, stripping length, and other parameters. It can store processing parameters for different wires, enabling quick setup and repeatable operations. Free sample testing is offered for optimization.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
