SU-150
| Availability: | |
|---|---|
| Quantity: | |
This series of machines is designed for fully automatic cutting and stripping of large-size cables, making them ideal for applications such as automotive power cables, electric control cabinet cables, battery box cables, new energy vehicle wiring harnesses, high-power supply shielding cables, and charging pile harnesses. They are also suitable for silicone wires, high-temperature wires, signal wires, and more.
1. Capable of processing cables up to 120/150 sqmm, significantly improving work efficiency.
2. Supports longer stripping lengths compared to standard machines.
3. Belt-driven cable feeding ensures no embossing or scratches on the wire surface.
4. Automatically identifies the machining center to increase production rates.
5. Uses specific axial positioning and advanced tool holders for improved accuracy and productivity.
6. Digitally displays wire diameter settings, with high-quality pneumatic components for stable and energy-saving operation.
7. Optional auxiliary equipment includes automatic wire feeders, wire stackers, or coilers.
| Model | SU-120 | SU-150 |
| Available Wire Size | AWG7 – 120mm² | AWG7 – 150mm² |
| Conductor Cross-Section | 10-120mm² | 10-150mm² |
| Cutting Length | 1-99999.99mm | 1-99999.99mm |
| Cutting Length Tolerances | ≤(0.002*L) mm | ≤(0.002*L) mm |
| Stripping Length * | Head 1-800mm; Tail 1-400mm | Head 1-800mm; Tail 1-400mm |
| Conduit Diameter * | Φ30mm | Φ33mm |
| Production Rate | 1000-1800pcs/h | 1000-1800pcs/h |
| Display Screen | 7 inch touch screen | 7 inch touch screen |
| Wire Feed Method | Belt feeding | Belt feeding |
| Drive Method | 32 wheels drive | 32 wheels drive |
| Power Supply | 220V/110V | 220V/110V |
| Power | 2000W | 6900W |
| Weight | 220kgs | 240kg |
| Dimensions | 102*61*115cm | 150*76*134cm |
| Note: * mark parameters custom available. If you are in doubt, we are happy to process your sample. | ||
Application
The series machines are designed for full-automatic cut and strip big size cable.
The SU-120 and SU-150 are fully automatic heavy-duty cutting and stripping machines for large cables up to 120mm² and 150mm². They process automotive power cables, control cabinet cables, new energy vehicle harnesses, and charging pile cables.
The SU-120 processes 10-120mm², while the SU-150 handles 10-150mm² (both AWG7 and up). Both cut lengths from 1-99999.99mm with tolerance ≤(0.002*L)mm. Stripping: head 1-800mm, tail 1-400mm (custom available).
Both models offer a production rate of 1000-1800 pieces per hour. They use 32-wheel belt-driven feeding to prevent surface marks, and automatically identify the machining center to increase accuracy and production rates.
Key features include belt-driven feeding that protects wire surfaces, digital wire diameter display on a 7-inch touch screen, 32-wheel drive for stable feeding, and optional auxiliary equipment (wire feeders, stackers, coilers).
Both require 220V/110V power (SU-120: 2000W, SU-150: 6900W). Dimensions: SU-120 102*61*115cm (220kg), SU-150 150*76*134cm (240kg), requiring dedicated floor space. A 7-inch touch screen facilitates operation.
The system uses specific axial positioning and advanced tool holders for accuracy. It digitally displays settings for easy adjustment. Custom conduit diameters (Φ30mm for SU-120, Φ33mm for SU-150) are available, and free sample testing is offered.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
