RG-B50 Double-Outlet Heat-Shrinkable Tube Heating Air Gun
The RG-B50 is a high-performance heat-shrinkable tube heating air gun designed for efficient and precise heating. Featuring dual air vents and compact design, it is especially suitable for assembly line installations and heating large-diameter heat-shrinkable tubes. With its high thermal efficiency, stable power output, and accurate temperature control, this air gun ensures consistent and reliable operation.
Key Features:
1. Digital Temperature Adjustment
Each outlet is equipped with a temperature sensor for precise control.
Unified temperature control for both outlets, with digital adjustment to meet specific heating needs.
2. Stable Power Output
Ensures consistent and reliable heating performance, even during long operating periods.
3. Innovative Wind Tunnel Design
Air passes evenly through the interior and exterior of the spiral heating wire.
Achieves nearly 100% heat exchange efficiency with minimal wind pressure loss.
4. Durable and Reliable Construction
Double-layer heat insulation and a robust stainless steel cabinet ensure safety and reliability.
Capable of maintaining high-temperature operation continuously for 24 hours without interruption.
5. Compact and Portable
Lightweight and small in size, making it easy to move and integrate into various workspaces.
| Model | RG-B50 |
| Air outle diameter | Standard 50mm; Optional 25mm |
| Insulation layer material | Multi-fiber thermal insulation cotton |
| Heater | Heating wire |
| Heater power | 2*2KW |
| Heating wire life | 10000h |
| Power regulation | Adjust the voltage through a potentiometer |
| Blower power | 50W |
| Max air volume | 198M3/H,the actual air volume is about 98M3/H |
| Static pressure | 298pa |
| Max working temperature | <350℃ (temperature control ±2℃) |
| Power supply | 220V |
| Power | 4100W |
| Weight | 20KG |
| Dimension | 91*52*85cm |
Application
The RG-B50 is a high-performance heat-shrinkable tube heating air gun featuring dual air vents for efficient heating of large-diameter heat-shrinkable tubes, ideal for assembly line installations.
It features dual heaters (2×2KW), 4100W total power, max temperature <350°C with ±2°C control, 198M³/H max air volume, 50W blower, and operates on 220V. Weight: 20kg, dimensions: 91*52*85cm.
Key features include dual air vents with independent temperature sensors, unified digital temperature control, innovative wind tunnel design for nearly 100% heat exchange efficiency, double-layer heat insulation with stainless steel cabinet, and 24-hour continuous operation capability.
The RG-B50 requires 220V power (4100W total) and has dimensions of 91*52*85cm, weighing 20kg. It is a compact unit suitable for benchtop or assembly line installation.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
