SP-3035
| Availability: | |
|---|---|
| Quantity: | |
Description
The SP-3035 is a compact pneumatic wire stripping machine designed for the inner cores of multi-core sheathed cables and charging gun cables. It processes conductors from 2.5 mm² to 35 mm², equivalent to AWG14–AWG2, without changing blades or adjusting the machine for different wire sizes.
The machine supports stripping lengths from 2 mm to 30 mm and is suitable for high-volume wire harness production where quick changeover, simple operation, and reduced maintenance are required.
Key Features:
No Blade Change Required – Strips different wire sizes without changing blades or making repeated diameter adjustments.
Wide Conductor Range – Processes 2.5–35 mm² conductors, equivalent to AWG14–AWG2.
Pneumatic Control – The cylinder-driven structure provides stable stripping performance and convenient operation.
Imported Pneumatic Components – Supports accurate operation and long service life.
Compact and Portable Design – The 15 kg machine is easy to move and install at different workstations.
Multi-Core Cable Applications – Suitable for stripping inner cores of sheathed cables, charging gun cables, armored cables, submersible cables, and underground feeder cables.
| Model | SP-3035 |
| Features | No blade change required for different wire diameters |
| Available Wire Size | AWG 2 – AWG 14 |
| Conductor Cross-Section | 2.5 – 35 mm² |
| Stripping Length | 2 – 30 mm |
| Air Connection | 0.5 – 0.7 MPa |
| Weight | 15 kg |
| Dimensions | 36 × 29 × 18 cm |
Inner cores of multi-core sheathed cables
Charging gun cables
Armored cables, submersible cables, and underground feeder cables
Small and large wire stripping
The SP-3035 is a compact pneumatic wire stripping machine for inner cores of multi-core sheathed cables and charging gun cables, processing conductors from 2.5mm² to 35mm² without blade changes.
Available wire size: AWG2-AWG14. Conductor cross-section: 2.5-35mm². Stripping length: 2-30mm. Air connection: 0.5-0.7MPa. Dimensions: 36×29×18cm, weight: 15kg.
Key features include no blade change required for different wire diameters, wide conductor range (2.5-35mm²), pneumatic cylinder-driven control, imported pneumatic components for long service life, and compact portable design at only 15kg.
It is suitable for stripping inner cores of sheathed cables, charging gun cables, armored cables, submersible cables, and underground feeder cables, as well as multi-core cables with different diameter inner cores.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
