TU-SD15 TU-SD20 TU-SD30
| Availability: | |
|---|---|
| Quantity: | |
Description
This series of servo-driven crimping units is primarily engineered for terminal crimping applications involving large-cross-section square wires. The system operates on an AC servo motor, transmitting output force through a high-precision ball screw mechanism, thereby enabling both pressure assembly and pressure-displacement monitoring functionalities.
This crimping solution is ideally suited for large tubular terminals (both standard square types and non-standard specifications).
Key Features:
An industrial-grade control chip, working in tandem with a high-performance servo drive, ensures consistent and reliable machine operation.
The integrated PLC-based control system allows for instantaneous crimping parameter adjustments to accommodate different terminal types without prolonged changeover time.
Tooling changeover is eliminated when processing terminals of varying sizes, streamlining the crimping workflow.
The machine supports multiple crimping profiles, including hexagonal, quadrilateral, and M-shaped configurations.
Crimping position can be fine-tuned to suit different square-wire gauges.
Available in both benchtop (desk-type) and floor-standing configurations to meet diverse workshop layouts and production demands
Technical Data – Large Series
Application
Cable lug terminal crimping samples
The TU-SD15, TU-SD20, and TU-SD30 are servo-driven terminal crimping machines for heavy-duty wire harness processing with large-cross-section square wires, delivering 15T, 20T, and 30T crimping force respectively.
TU-SD15: 15T; TU-SD20: 20T; TU-SD30: 30T. All feature 40mm stroke with AC servo motor and ball screw drive, supporting standard terminals up to 120mm².
Key features include AC servo motor with high-precision ball screw mechanism, PLC-based control for instant parameter adjustment, tooling changeover elimination for different terminal sizes, and support for hexagonal, quadrilateral, and M-shaped crimping profiles.
The machines are available in both benchtop (desk-type) and floor-standing configurations to suit diverse workshop layouts and production demands.
Specific power and dimension details are not provided on the page. The machines are designed for heavy-duty terminal crimping applications with large square tubular terminals. Please contact Wirepro directly for detailed specifications.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
