RD-MT
| Availability: | |
|---|---|
| Quantity: | |
RD-MT Electric Heating Air Heater
The RD-MT is an efficient and reliable electric heating air heater designed specifically for large-diameter heat-shrinkable tubing. Its innovative 360-degree infrared radiation heating ensures uniform and thorough heat distribution, making it ideal for processing large wiring harnesses, long harnesses, and terminal wiring harnesses.
Equipment composition with heating system + control system + rack desk.
Key Features:
1. 360-Degree Infrared Radiation Heating: The machine uses surrounding infrared radiation to achieve uniform heating, ensuring consistent results for all tubing sizes.
2. Versatile Operation: For end-positioned tubing, operators can directly insert the tube into the heating zone.
For mid-positioned tubing, the device can be opened to place the tubing in the heating zone, providing flexibility for various applications.
3. Advanced Safety Features: Equipped with overheat and overload protection, power-off safety mechanisms, andan emergency stop switch. The machine is environmentally friendly, operating without exhaust gas, and capable of continuous 24-hour use.
4. Prolonged Heating Core Life: Includes a shutdown and blowing delay function, allowing the blower to continue cooling the heating core for one minute after the machine stops to extend the core's lifespan.
5. Energy-Saving Heat Insulation Design:The double-layer heating zone shell design minimizes energy consumption and protects the working environment from excessive heat.
Three Heating Control Modes:
1. Footswitch Activation: Heating starts when the product is placed and triggered by the footswitch.
2. Automatic Cycling Mode: The machine heats and stops in a preset, continuous cycle for efficient production.
3. Temperature Control Mode: Maintains a constant temperature for normal heating operations.
Model | RD-MT |
Heating shrinkable tube diameter | < 100mm |
Heating opening diameter | 120mm |
Heating length | < 160mm |
Heating tube name | Infrared radiation tube (2400W) |
Power supply | 220V |
Power | <2800W |
Weight | 60kg |
Dimension | 140*130*60cm |
Application
The RD-MT is an efficient electric heating air heater designed for large-diameter heat-shrinkable tubing using 360-degree infrared radiation heating for large wiring harnesses, long harnesses, and terminal wiring harnesses.
It supports heat shrink tubing diameters up to 100mm with heating opening of 120mm and heating length up to 160mm. It uses infrared radiation tube heating with power under 2800W.
Key features include 360-degree infrared radiation for uniform heating, versatile operation for end-positioned and mid-positioned tubing, three heating control modes (footswitch, automatic cycling, temperature control), and safety features including overheat/overload protection.
The RD-MT requires 220V power (<2800W) and has dimensions of 140*130*60cm, weighing 60kg. It requires dedicated floor space.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
