PF-S20/PF-S30/PF-S40/PF-S50/PF-S60
| Availability: | |
|---|---|
| Quantity: | |
Description
The PF-S20 is a passive wire stacking system featuring a guide channel and collecting tray, designed to work in conjunction with automatic wire processing machines. The maximum cable length can be customized to suit specific production requirements.
After each wire is processed, the machine sends a control signal to the wire stacker, causing the wire to drop from the collection tube into the collection tray — enabling smooth, automated wire collection without manual intervention.
Key Features:
Cost-Effective Unattended Operation – A low-cost solution that allows automatic machines to run unattended, reducing supervision requirements.
Reduced Manual Handling – Greatly minimizes the labor involved in handling long wires, freeing operators for other tasks.
Passive Design – Built for almost unlimited, trouble-free cycles without complex drive mechanisms.
Customizable Handling Lengths – Available in multiple models with maximum load lengths from 2 m to 6 m, with custom options available.
Versatile Wire Compatibility – Works equally well with both short and long wires, accommodating cable sizes from 0.5 to 120 mm² and diameters up to 25 mm.
| Model | PC-S20 | PC-S30 | PC-S40 | PC-S50 | PC-S60 |
| Max Load Length | 2m | 3m | 4m | 5m | 6m |
| Available Cable | 0.5-120 sqmm (others can custom) | ||||
| Available Cable Dia | Max 25mm (other can customs) | ||||
| Speed Setting | 0 – 2m/s | ||||
| Power Supply | 220V / 110V | ||||
Typical Applications:
Works with fully automatic wire cutting and stripping machines
Works with automatic terminal crimping machines
Wire collection for long cable processing lines
The PC-S20 is a passive wire stacking system with guide channel and collecting tray, designed to work with automatic wire cutting, stripping, and crimping machines for unattended collection of processed wires.
Max load length options: PC-S20 (2m), PC-S30 (3m), PC-S40 (4m), PC-S50 (5m), PC-S60 (6m). Available cable: 0.5-120mm². Max cable diameter: 25mm. Speed: 0-2m/s. Power: 220V/110V.
Key features include low-cost unattended operation, greatly reduced labor for handling long wires, passive design for unlimited trouble-free cycles, customizable handling lengths, and equal performance with short or long wires.
The PC-S20 series operates on 220V/110V power. Specific dimensions and weight are not provided on the page. The system requires space corresponding to the selected max load length (2m-6m). Please contact Wirepro for detailed specifications.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
