TU-NH2 / TU-NH3 / TU-NH4
| Availability: | |
|---|---|
| Quantity: | |
Description
The TU-NH2, TU-NH3, and TU-NH4 are semi-automatic terminal crimping machines suitable for various terminal types, with very easy applicator changeover. They are suitable for crimping computer terminals, DC terminals, AC terminals, single grain terminals, joint terminals, and more.
This is an automatic high-speed, super-quiet terminal crimping machine. It is easy to operate and repair, designed for high output and low maintenance. Using frequency conversion technology and electronic precision positioning, it operates with less noise than traditional terminal machines while saving power. Applicator adjustment is convenient and swift.
Functions:
Voltage stability, high speed, and high accuracy.
Used for computer terminals, DC terminals, single terminals, and wire terminals.
Lightweight structure — easy to move, with low noise operation.
The machine is capable of fitting 3 mold types: vertical applicator, horizontal applicator, and single terminal applicator. Please specify your required mold when ordering.
| Model | TU-NH2 | TU-NH3 | TU-NH4 |
| Crimp Force | 2.0Ton | 3.0Ton | 4.0Ton |
| Stroke | 30mm (custom available) | ||
| Power Supply | 110/220VAC,50/60Hz | ||
| Power | 750W | 1100W | 1500W |
| Weight | 85kg | 90kg | 93kg |
| Dimensions | 25*28*69cm | 25*28*69cm | 26*30*71cm |
Wire stripping and ring terminal crimping
Various terminal crimping applications
Wire harness assembly
The TU-NH2, TU-NH3, and TU-NH4 are semi-automatic terminal crimping machines for computer terminals, DC/AC terminals, single grain terminals, and joint terminals, featuring ultra-quiet frequency conversion technology.
TU-NH2: 2.0T, 750W, 85kg. TU-NH3: 3.0T, 1100W, 90kg. TU-NH4: 4.0T, 1500W, 93kg. All: 30mm stroke (custom), 110/220VAC, 50/60Hz. Dimensions: TU-NH2/NH3 25*28*69cm, TU-NH4 26*30*71cm.
The machines can fit three mold types: vertical applicator, horizontal applicator, and single terminal applicator. Please specify your desired mold type when ordering.
Key features include frequency conversion technology for ultra-quiet operation, electronic precision positioning, voltage stability with high speed and accuracy, power saving, convenient applicator adjustment, and lightweight structure for easy movement.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
