SP-M03
| Availability: | |
|---|---|
| Quantity: | |
Description
The SP-M03 is a semi-automatic stripping machine engineered for processing multi-core cables with varying lengths. It delivers precise insulation removal for discrete wires, solid wires, single-stranded wires, and single-core cables in production environments.
Featuring a compact and lightweight design (26*15*27cm, 2kg), the machine operates on a pneumatic system (0.5–0.8MPa) and accommodates wire sizes from AWG32 to AWG14 (conductor cross-section 0.03–2.08mm²). It supports a maximum stripping length of 18mm and maintains a high precision tolerance of 0.01mm (0.001″).
The SP-M03 is ideal for applications requiring accurate, repeatable stripping of small-gauge multi-core cable assemblies. Customizable size options and free sample testing are available to meet specific production requirements.
Model | SP-M03 |
Features | For small wire stripping |
Available Wire Size | AWG32 – AWG14 |
Conductor Cross-Section | 0.03–2.08mm² |
Wire Diameter | 3.2mm ( 0.12″ ) |
Stripping Length | Max 18mm |
Stripping Length Tolerance | 0.01 mm (0.001″) |
Air Connection | 0.5MPa – 0.8MPa |
Weight | 2kg |
Dimensions | 26*15*27cm |
Application
For small wire stripping
The SP-M03 is a semi-automatic small wire stripping machine designed for processing multi-core cables with different lengths. It is used for precision stripping of discrete wires, solid wires, single-stranded wires, and single-core cables in production environments.
It processes AWG32 to AWG14 wire, with a conductor cross-section of 0.03–2.08mm² and a maximum outer wire diameter of 3.2mm (0.12″). The maximum stripping length is 18mm, making it suitable for small-gauge multi-core cable applications.
The SP-M03 achieves a stripping length tolerance of 0.01 mm (0.001″), ensuring high precision for sensitive multi-core cable processing. Specific processing speed is not listed on the page.
Its key features include high-precision stripping with 0.01mm tolerance, capability to process multi-core cables with different lengths, and a compact design. It also offers free sample testing for standard machines and customizable size options.
The SP-M03 requires an air connection of 0.5MPa – 0.8MPa. It has compact dimensions of 26*15*27cm and weighs 2kg, allowing for easy integration into multiple workstations without significant space demands.
The machine is designed for small wire stripping and can process various wire types within its specified range. For specific size requirements beyond standard, the page indicates that some sizes can be custom ordered.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
