SP-3010
| Availability: | |
|---|---|
| Quantity: | |
This machine is ideal for stripping various types of electronic wires, power cords, and sheathed core wires with different diameters.
1. It features a fully pneumatic design, eliminating the need for electrical power and allowing seamless operation without the need for tool replacements or adjustments for different wire sizes.
2. The cutting tool uses four blades arranged in a 90-degree cross pattern, ensuring clean and precise stripping while preventing damage to the core wire and reducing conductor bending, unlike two-blade systems.
3. The cutting depth is easily adjustable, supporting full and partial stripping with precise length control.
4. The machine boasts a compact and ergonomic structure, offering simple operation and excellent safety features.
Model | SP-3010 | SP-3025 |
Features | Don’t change the knife for different wires, induction start. | |
Conductor Cross-Section | 0.5-6mm² ( max 10 mm² ) | 0.5-25mm² |
Stripping Length | 2-50mm | 3-60mm |
Air Connection | 0.5MPa – 0.7MPa | 0.5MPa – 0.7MPa |
Production Rate | 1500 – 2000 pcs/h | 1500 – 2000 pcs/h |
Weight | 25kg | 30kg |
Dimensions | 40*37*20cm | 48*38*20cm |
Application
For small wire stripping
The SP-3010 and SP-3025 are pneumatic, adaptable-blade wire strippers designed for stripping electronic wires, power cords, and sheathed core wires. They operate without electrical power, using a four-blade cross pattern for clean stripping of various wire diameters.
The SP-3010 handles 0.5-6mm² (max 10mm²) with a 2-50mm stripping length. The SP-3025 processes 0.5-25mm² with a 3-60mm length. Both support full and partial stripping with adjustable cutting depth.
Both the SP-3010 and SP-3025 models offer a production rate of 1500 – 2000 pieces per hour, making them suitable for medium to high-volume wire processing tasks in production environments.
Key differentiators include the adaptable blade design that eliminates tool changes for different wire sizes, a four-blade system that prevents core damage, and fully pneumatic operation requiring no electrical power. It also offers free sample testing.
Both models require an air connection of 0.5MPa – 0.7MPa. The SP-3010 weighs 25kg with dimensions 40*37*20cm, while the SP-3025 weighs 30kg with dimensions 48*38*20cm, requiring modest benchtop space.
The adaptable blade system automatically accommodates different wire diameters, eliminating the need for blade changes or adjustments. For specific custom wire sizes, the manufacturer offers customization options to meet unique requirements.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
