SC-D07
| Availability: | |
|---|---|
| Quantity: | |
This programmable semi-automatic coaxial cable stripping machine features a unique two-cutter design, enabling it to process a wide range of wires and cables. It handles even thin, tough, or slightly irregular materials with ease. The machine supports cables with a maximum diameter of up to 10mm and a stripping length of up to 65mm.
Features:
1. Rotary Stripping Head: Ensures enhanced stability and extends the machine's working life.
2. Multi-Layer Capability: Supports stripping up to 9 layers, with options for multi-layer and multi-stage peeling
3. High Precision: Equipped with a servo motor, precision ball screw, and multi-point motion control system for stable and efficient operation.
4. Durable Stripping Tool: Made of high-quality steel with an optional titanium alloy coating for durability and sharp performance.
This machine offers precision and efficiency, making it ideal for demanding cable stripping applications.
| Model | SC-D07 | SC-D10 |
| Features | Rotary knife cutter stripping | Rotary knife cutter stripping |
| Available Wire Dia | 0.81-7mm | 1- 10mm |
| Stripping Length * | ≤48mm | ≤65mm |
| Blade Quantity | 2 pieces | 4 pieces |
| Production Rate | 700-1200pcs/h | 700-1200pcs/h |
| Stripping Layers | Max 9 layers | Max 9 layers |
| Display Screen | Chinese / English touch screen | Chinese / English touch screen |
| Power Supply | 220V/110V | 220V/110V |
| Power | 240W | 400W |
| Dimensions | 60*18.5*28cm | 60*18.5*28cm |
| Weight | 24kg | 25kg |
| Note: * mark parameters custom available. If you are in doubt, we are happy to process your sample. | ||
Application
Stripping coaxial cable, max 9 layers.
Applicable to all kinds of flexible and semi-flexible coaxial cable in the communication industry and medical automotive industry etc.
The SC-D07 is a programmable semi-automatic coaxial cable stripping machine with a two-cutter design. It is used for processing coaxial cables in communication, medical, and automotive industries, handling thin, tough, or slightly irregular materials with precision.
It processes wire diameters from 0.81-7mm with a maximum stripping length of ≤48mm. For comparison, the SC-D10 model handles 1-10mm diameters with ≤65mm stripping length. Custom lengths are available upon request.
The SC-D07 offers a production rate of 700-1200 pieces per hour. It is equipped with a servo motor, precision ball screw, and multi-point motion control system for stable and efficient high-precision operation.
Key differentiators include a four-cutter design, ability to strip up to 9 layers (multi-layer and multi-stage peeling), a durable stripping tool with optional titanium alloy coating, and a rotary stripping head for enhanced stability and longer working life.
The SC-D07 requires 220V/110V power (240W) and has compact dimensions of 60*18.5*28cm, weighing 24kg. It features a Chinese/English touch screen for easy operation and setup.
The programmable system with multi-point motion control allows for easy adjustment to different cable types. The machine supports up to 9 stripping layers, and the manufacturer offers free sample testing to determine optimal settings for your specific cables.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
