RC-A01
| Availability: | |
|---|---|
| Quantity: | |
The RC-A01 is an advanced machine designed for the automatic feeding, cutting, loading, and heating of heat shrink tubes.
1 unit RC-A01 = 1 heat shrink tube cutting machine + 1 heat shrink tube heater + 0.5 operator
This machine is widely utilized in wire harness production, electronic connection wires, substrate terminal connection wires, power cables, and AC/DC wires. It significantly enhances the efficiency of heat shrink tube operations, addressing the challenges of traditional manual methods.
Important Note: Ensure the heat shrink tube diameter is larger than the maximum terminal diameter to allow proper loading after terminal crimping.
Key Features：
1. Smart Automation: Equipped with a PLC touch screen for easy operation and stable performance;
2. Fully Automated Process: Automatically feeds, cuts, loads, and shrinks heat shrink tubes, eliminating the complexity of manual handling;
3. High Efficiency: Capable of processing approximately 1,200 heat shrink tubes per hour (production capacity may vary by product), saving time and boosting productivity;
4. Customizable Parts: Certain components can be tailored to match specific tube sizes and product requirements.
Model | RC-A01 |
Available Tube Diameter | 1-5.5 (others please check with us) |
Available Tube Length | 5-25 mm(others please check with us, one machine recommends the length max and min not more than 5 mm difference) |
Tube Length Tolerance | ± 0.3 mm |
Tube Positioning Tolerance | ± 0.2 mm |
Production Rate | 700-1200 pcs/hour |
Yield | 99% |
Compressed Air Supply | 0.5 – 0.6 Mpa |
Power | 220/110V |
Power Supply | 1000W |
Dimensions | 70*80*125cm |
Weight | about 200kg |
Application
The RC-A01 is an advanced machine for automatic feeding, cutting, loading, and heating of heat shrink tubes, integrating cutting and heating functions for wire harness production and electronic connection wires.
It supports tube diameters of 1-5.5mm (others consult) and lengths of 5-25mm (max-min difference ≤5mm per machine). Tube length tolerance: ±0.3mm, positioning tolerance: ±0.2mm.
The machine processes 700-1200 pieces per hour with 99% yield. It features PLC touch screen control for stable performance and fully automated feeding, cutting, loading, and shrinking.
Key features include integrated feeding, cutting, loading, and heating in one unit, PLC touch screen control, customizable components for specific tube sizes, and significant labor savings (1 unit = 1 cutter + 1 heater + 0.5 operator).
The RC-A01 requires 220/110V power (1000W) and 0.5-0.6MPa compressed air. Dimensions: 70*80*125cm, weight: about 200kg. Requires dedicated floor space.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
