PF-S38
| Availability: | |
|---|---|
| Quantity: | |
This fully automated wire feeder streamlines the wire feeding process, eliminating the need for manual handling. It is compatible with a wide range of wires and cables, making it a versatile solution for various applications.
Specifications:
1. Durable Construction: Built with high-quality national standard rectangular tubing, ensuring a robust structure and an aesthetically pleasing design.
2. High Efficiency: Offers a maximum feeding speed of 4 m/s, enabling fast and smooth operation.
3. Wide Compatibility: Supports wires with a diameter of up to 18mm, accommodating diverse needs.
| Model | PF-S38 |
| Available Wire Diameter | ≤ Φ18mm |
| Available Spool Width | 380mm |
| Available Spool Out Diameter | 100-400mm |
| Available Spool Inner Diameter | 38-45mm |
| Max Load Weight | 60kg |
| Feeding Speed | 0-4m/s |
| Power Supply | 220/110V,50/60Hz |
| Power | 750W |
| Available Wire | Wire, cable etc. |
| Drive Type | Inverter & motor & reducer |
| Dimensions | 75*40*110cm |
| Weight | 80 kg |
Application
This fully automatic wire feeder eliminates the trouble of manual wire feeding.
The PF-S38 is a fully automated wire spool unwind machine and prefeeder that streamlines wire feeding, eliminating manual handling for wires and cables up to Φ18mm.
Wire diameter: ≤Φ18mm. Spool width: 380mm, OD: 100-400mm, ID: 38-45mm. Max load: 60kg. Feeding speed: 0-4 m/s. Power: 220/110V, 750W. Dimensions: 75*40*110cm, weight: 80kg.
Key features include high-speed feeding up to 4 m/s, durable construction with national standard rectangular tubing, wide spool compatibility (100-400mm OD), and inverter & motor & reducer drive for smooth operation.
The PF-S38 requires 220/110V, 50/60Hz power (750W) and has dimensions of 75*40*110cm, weighing 80kg. Requires moderate floor space.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
