HW-HD35
| Availability: | |
|---|---|
| Quantity: | |
HW-HD35 & HW-HD55 Taping Machine Features
1. Lightweight and Portable: Weighing only 8kg, the machines are easy to move and highly convenient for various work environments.
2. Versatile Taping Options: Supports both point taping and full taping, with adjustable winding speed and turns to suit your needs.
3. Efficient Cutting Mechanism: Features an integrated tooth-shaped incision and hidden blade, capable of cutting tapes of various materials.
4. Automatic Positioning: After completing one taping cycle, the tape automatically advances to the next position, eliminating unnecessary manual steps.
5. Optimized for Branch Taping: Equipped with a turntable opening, perfect for taping branches and accommodating larger diameter wire harnesses.
6. Ergonomic Design: Designed with human mechanics in mind, ensuring ease of operation and reducing operator fatigue during prolonged use.
Model | HW-HD35 | HW-HD55 |
Features | Desktop | Desktop, big diameter |
Available Wire Dia | Φ5-35mm (others need to test) | Φ5-55mm (others need to test) |
Tape Width | 5-25mm (There are recommended tape widths for different wire diameters) | 5-25mm (There are recommended tape widths for different wire diameters) |
Tape Roll OD | Recommend less than Φ90mm, Max Φ105mm | Recommend less than Φ110mm, Max Φ125mm |
Wrapping Speed | Manual control | Manual control |
Power Supply | 110/220VAC,50/60Hz Optional battery power | 110/220VAC,50/60Hz Optional battery power |
Dimensions | 25*30*35cm | 25*30*38cm |
Weight | 8kg | 10kg |
Application
HW-HD35 supports wire harness continuous & spot taping.
The HW-HD35 and HW-HD55 are desktop wire harness taping machines designed for point taping, full taping, and branch taping of large diameter wire harnesses in automotive and industrial applications.
HW-HD35 supports Φ5-35mm wire diameter; HW-HD55 supports Φ5-55mm (others need testing). Both support tape widths of 5-25mm with recommended widths varying by wire diameter.
Key features include integrated tooth-shaped incision with hidden blade for cutting various tape materials, automatic positioning after each taping cycle, turntable opening optimized for branch taping, and adjustable winding speed and turns.
Both models operate on 110/220VAC, 50/60Hz with optional battery power. Dimensions: HW-HD35 25*30*35cm, HW-HD55 25*30*38cm. Weights: 8kg and 10kg respectively.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
