TA-D21
| Availability: | |
|---|---|
| Quantity: | |
Description
The TA-D21 is a fully automatic wire processing machine designed for two-end cutting, stripping, and terminal crimping in a single, streamlined cycle. Engineered for high efficiency and precision, this series is ideal for manufacturers requiring consistent, reliable termination of one-core small wires and ferrules.
Key Features:
Fully Automatic Two-End Processing – Completes cutting, stripping, and terminal crimping on both wire ends in one continuous operation, significantly boosting production efficiency.
High Configuration – Equipped with advanced components and control systems to ensure stable performance and superior crimping quality.
Precision Crimping – Delivers accurate and consistent terminal crimping results, essential for small-gauge wires and ferrule applications.
User-Friendly Operation – Intuitive interface simplifies setup, parameter adjustment, and job changeover, reducing operator training time.
Versatile Applicator Support – Compatible with a wide range of terminal applicators, enabling flexible configuration for different terminal types and wire sizes.
Robust Construction – Built for durability in continuous production environments, ensuring long-term reliability and minimal downtime.
Typical Applications:
One-core small wire terminal crimping
Ferrule termination for electrical connections
Wire harness assembly for electronics and appliances
Automotive and industrial wiring
| Model | TA-D21 | TA-D22 | TA-D23 |
| Available Wire Size | 0.1-0.5 mm² | 0.5–2.5 mm² | 2.5–4 mm² |
| Available Wire Size | AWG27-20# | AWG20-13# | AWG13-11# |
| Cutting Length | 45-999mm | ||
| Length Tolerance | ±0.2%*L | ||
| Stripping Length | 0-10mm | ||
| Detection Device | Lack wire detection, Lack terminal detection, Crimp detection, Pressure detection | ||
| Machine Production Rate | About 4000 pcs/h | ||
| Air Connection | 0.4-0.6MPa | ||
| Power Supply | 110/220VAC,50/60Hz | ||
| Power | 2300W | ||
| Weight | About 320kg | ||
| Dimensions | 120*60*200cm | ||
Application
Fully automatic two-ends wire cutting stripping and terminal crimping machine.
The TA-D21, TA-D22, and TA-D23 are fully automatic two-ends wire cutting, stripping, and terminal crimping machines. They process wires from 0.1mm² to 4mm² (AWG27-11#) with a production rate of about 4000 pieces per hour.
TA-D21 handles 0.1-0.5mm² (AWG27-20#); TA-D22 handles 0.5-2.5mm² (AWG20-13#); TA-D23 handles 2.5-4mm² (AWG13-11#). All feature cutting lengths 45-999mm, stripping 0-10mm, and operate on 110/220VAC, 50/60Hz (2300W).
All models are equipped with comprehensive detection including lack wire detection, lack terminal detection, crimp detection, and pressure detection, ensuring consistent quality and reducing defective products.
Key features include a dual motor feeding system for precise length control, compatibility with both horizontal and vertical applicators, ultra-quiet crimping mechanism with uniform intensity, and advanced touch screen technology for easy programming.
All models require 110/220VAC, 50/60Hz power (2300W) and share dimensions of 120*60*200cm, weighing approximately 320kg. They are floor-standing units requiring dedicated floor space.
The touch screen allows easy adjustment of cutting length, stripping length, and other parameters. Each model is optimized for a specific wire range, and free sample testing is offered to optimize settings for specific wire types.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
