HT-C05
| Availability: | |
|---|---|
| Quantity: | |
This motorized tensile testing machine is designed for precise and efficient testing of wire harnesses and terminals, offering intuitive operation and real-time data analysis.
Features:
1. Motor-driven with color touch screen interface; automatic tension measurement ensures easy operation and high accuracy.
2. Supports both peak tensile force testing and non-destructive testing by setting upper force limits and test duration.
3. Equipped with self-developed software for real-time graph display, computer/printer communication, and immediate test result printing.
4. Built-in memory can store up to 16 testing programs to handle routine wire testing needs.
5. Versatile clamp design fits a variety of wire and terminal sizes; custom options available for special specifications.
Model | HT-C05 | HT-C10 |
Force Range | 0~500N | 0~1000N |
Force Accuracy | ±0.04N | ±0.04N |
Force Unit | Kilogram(Kg) / Newton(N) | Kilogram(Kg) / Newton(N) |
Power Supply | 220V | 220V |
Power | 100W | 100W |
Test speed | 10-800mm/min | 10-800mm/min |
Weight | 10kg | 10kg |
Dimensions | 43×18×21cm | 43×18×21cm |
Application
The HT-C05 and HT-C10 are motorized tensile testing machines for precise testing of wire harnesses and terminals, featuring color touch screen interface and real-time data analysis.
HT-C05: 0-500N, ±0.04N accuracy. HT-C10: 0-1000N, ±0.04N accuracy. Both: test speed 10-800mm/min, 220V power, 100W, dimensions 43*18*21cm, weight 10kg.
Key features include color touch screen interface, automatic tension measurement, peak and non-destructive testing modes, self-developed software for real-time graphs and printing, built-in memory for up to 16 programs, and versatile clamp design.
Both models require 220V power (100W) and have dimensions of 43*18*21cm, weighing 10kg. They are compact benchtop units.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
