HT-E30
| Availability: | |
|---|---|
| Quantity: | |
Wire Terminal Pull Test Machine - HT-E30
The HT-E30 is a highly accurate testing device designed for wire harness pull-off testing in the wire harness manufacturing industry. One of the key upgrades in this model is its compatibility with the MES system, allowing for seamless data transfer via USB for easy integration.
Standard Features:
MES System Integration: Upload test data directly to the MES system for efficient management.
Optional Features:
Barcode Scanner: Quickly input material numbers using the software.
PC Software Interface: View real-time testing graphs and generate reports directly from the computer.
Wi-Fi Connectivity: Connect the device to your network for enhanced functionality.
Label Printer: Generate QR codes and print test data for documentation.
Key Features:
1. Automatic Reset: Set conditions for automatic reset after pulling off the terminal.
2. System Settings: Easily adjust system parameters, including test limits, calibration, and pull-off conditions.
3. Force Limit Detection: Automatically marks the test as NG if the force exceeds set upper or lower limits.
4. Unit Conversion: Quickly convert between kg, N, and LB units; pre-set to preferred units upon power-up.
5. Real-Time Data Display: Monitor both real-time and peak tension simultaneously.
6. Data Processing: Effortlessly record, transmit, and clear test data for further analysis and reporting.
Model | HT-E30 |
Force Range | 0~1000N |
Force Accuracy | +0.05% (full scale) |
Force Unit | Kilogram(Kg) / Newton(N) |
Power Supply | 220V/110V, 50Hz/60Hz |
Working Environment | -10 to 50℃ |
Traction speed | 25 / 50 /100 mm/min, or you can set by yourself |
Weight | 10.5kg |
Dimensions | 40*15*12cm |
The HT-E30 is a highly accurate testing device designed for wire harness pull-off testing, featuring MES system integration for seamless data transfer and quality control in manufacturing.
Force range: 0-1000N. Force accuracy: ±0.05% full scale. Traction speed: 25/50/100 mm/min (customizable). Power: 220V/110V, 50/60Hz. Dimensions: 40*15*12cm, weight: 10.5kg.
Key features include MES integration via USB, automatic reset with settable conditions, force limit detection (NG marking), real-time data display, PC software with graphing and reporting, and optional barcode scanner, Wi-Fi, and label printer.
The HT-E30 operates on 220V/110V, 50/60Hz power and has dimensions of 40*15*12cm, weighing 10.5kg. It is a compact benchtop unit.
Optional accessories include barcode scanner for material number input, PC software interface for real-time graphs and reports, Wi-Fi connectivity for network integration, and label printer for QR codes and test data documentation.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
