TP-T28
| Availability: | |
|---|---|
| Quantity: | |
Description
The TP-T28 and TP-T50 are ultrasonic welding machines designed for welding cables onto terminals. They are widely used in automotive, electronics, motor, communication, and instrumentation industries for wire harness assembly. The TP-T28 supports wire sizes from 5-28mm² (some wires up to 35mm²) with 20KHz frequency and 4000W power, operating on 110/220VAC, 50/60Hz power supply.
Model | TP-T28 |
Welding capacity | Wire size range: 5-28mm2 ( some wire support max 35 sqmm) |
Frequency | 20K |
Power Supply | 110/220VAC,50/60Hz |
Power | 4000W |
Weight | 30kg + 10kgs |
Application
The ultrasonic wire harness welding machine is widely used in the fields of automobiles, electronic appliances, motors, communication equipment, mechanical equipment, instruments and so on.
The TP-T28 and TP-T50 are ultrasonic welding machines designed for welding cables onto terminals. They are widely used in automotive, electronics, motor, communication, and instrumentation industries for wire harness assembly.
TP-T28 supports wire sizes from 5-28mm² (some wires up to 35mm²) with 20KHz frequency. It operates on 110/220VAC, 50/60Hz power (4000W). Specifications for TP-T50 are not detailed on the page.
The TP-T28 requires 110/220VAC, 50/60Hz power (4000W). Dimensions are not provided on the page, but the unit weighs approximately 30kg (plus 10kg for accessories), indicating a benchtop or portable design.
Key features include ultrasonic welding technology for reliable metal bonding, support for a wide wire size range (5-28mm²), and application versatility across automotive, electronics, and communication industries. Free sample testing is offered.
The ultrasonic welding process accommodates various cable sizes within the supported range. Custom sizes are available upon request, and free sample testing is offered to optimize welding parameters for specific cable-terminal combinations.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
