HL-F32
| Availability: | |
|---|---|
| Quantity: | |
The HL-F32 is an upgraded version of the HL-F30, specifically designed to meet high-performance cable fold labeling requirements. With enhanced precision and user-friendly features, this model ensures greater stability, efficiency, and ease of operation for wire and wire harness labeling tasks.
Major Upgrades:
1. Servo Motor Precision: Delivers exceptional stability and precise positioning. Even large labels are automatically adjusted to meet high-accuracy labeling requirements.
2. One-Button Adjustment: Simplifies operation—just install the label, and the machine is ready to run without manual adjustments. This eliminates wasted time, labels, and the need for professional technicians.
Key Features:
1. Stable and Accurate Operation: Utilizes a servo motor for enhanced labeling precision and consistent performance.
2. One-Key Setup: Easy-to-use functionality ensures quick adjustments with no learning curve, saving time and improving usability.
3. Wide Compatibility: Capable of folding and labeling wires and harness products of various specifications, with a broad adjustment range.
4. German SICK Sensor: Advanced label electric eye quickly detects label gaps, ensuring accurate label placement and reliable operation.
5. Optional Add-Ons:
Automatic Feeding Function: Doubles production speed with seamless wire feeding.
Printing and Labeling Synchronization: Simultaneously prints and applies labels, ideal for frequently changing label content requirements.
6. Robust Mechanical Design: Ensures smooth, stable, and reliable labeling performance, even in high-demand production environments.
Model | HL-F32 |
Available Materials | Round shape cable, tube and others |
Available Diameter | 1.6-30mm ( based on materials, other size can be customized) |
Available label | Width: 5~45 mm (customized oversize) |
Available label roller | Outer diameter: Max 240mm |
Labeling precision | ± 0.1mm |
Labeling speed | 1500-2500pcs/hour |
Air connection | 0.4-0.6 Mpa |
Power supply | 220V/50Hz; 110V/60Hz |
Power | 250W |
Dimensions | 580*680*1000mm |
Weight | 86kg |
Application
Applicable wires: earphone cable, USB cable, power cord, air pipe, water pipe, etc.;
Applicable labels: self-adhesive labels, self-adhesive films, electronic supervision codes, barcodes, etc.;
Application examples: headphone cable labeling, power cord labeling, optical fiber cable labeling, cable labeling, tracheal labeling, warning label labeling machine, etc.
The HL-F32 is a precision wire cable label printing and marking system for high-performance cable fold labeling. It is used for labeling earphone cables, USB cables, power cords, optical fiber cables, and more with self-adhesive labels and barcodes.
It supports cable/tube diameters of 1.6-30mm (customizable). Label width: 5-45mm (customizable oversize); label length: 40-180mm (customizable oversize). Label roller OD ≤240mm, ID ≤76mm.
Key upgrades include servo motor precision for stable positioning, one-button adjustment for simplified operation, German SICK sensor for accurate label detection, and optional automatic feeding and printing/labeling synchronization.
The machine achieves labeling speed of 1500-2500 pieces/hour (depending on product size and operator speed) with labeling precision of ±0.1mm.
The HL-F32 requires 220V/50Hz or 110V/60Hz power (250W) and 0.4-0.6 MPa air connection. Dimensions: 580*680*1000mm, weight: 86kg. It requires dedicated floor space.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
