HB-C20
| Availability: | |
|---|---|
| Quantity: | |
This advanced cable tie machine integrates a vibration plate for automatic feeding of nylon cable ties to a handheld cable tie gun, allowing 360-degree operation without blind spots. The operator simply pulls the trigger, and the machine completes all tying steps efficiently.
Features:
1. Fully Automated Process: Pulling the trigger initiates automatic feeding, tightening, cutting, and waste collection, completing all actions seamlessly.
2. High Efficiency: Each tying cycle is completed in approximately 1.3 seconds (including auxiliary time), improving productivity to the level of replacing 7–8 workers, potentially saving over 20 million in annual wage costs.
3. Waste Management: Optional waste recovery system automatically collects remnants in a dedicated waste box.
4. Ergonomic Design: Lightweight handheld tool with a compact grip ensures ease of use and minimizes operator fatigue during prolonged operation.
5. Adjustable Tension: The tying intensity can be finely tuned using a simple knob.
6. User-Friendly Interface: Equipped with a PLC control system and a touch screen with Chinese/English display for intuitive operation.
7. Versatile Usage: Can function as a desktop cable tie machine or integrate with a robot for fully automated production lines.
This machine delivers exceptional speed, precision, and adaptability, making it an ideal choice for streamlining cable tying operations.
Model | HB-C20 |
Cable tie length | 80/100/120/150 mm (can be customized) |
Cable tie width | 3 – 5 mm |
Tying Diameter | 2 – 30 mm |
Tail length | 0 – 3mm |
Production speed | about 2000pcs/hour based on operation speed |
Power Supply | 110/220VAC,50/60Hz |
Power | 700W |
Dimensions | 650 * 650 * 720 mm |
Weight | 130kgs |
Application
The HB-C20 is a handheld cable tie bundling machine that integrates automatic feeding of nylon cable ties to a handheld gun for 360-degree operation, ideal for wire harness and cable bundling in various industries.
It supports cable tie lengths of 80/100/120/150mm (customizable) and widths of 3-5mm. Tying diameter ranges from 2-30mm with tail length of 0-3mm.
The machine achieves a production speed of about 2000 pieces per hour, with each tying cycle completed in approximately 1.3 seconds, effectively replacing 7-8 manual workers.
Key features include handheld gun for 360-degree operation, fully automated feeding/tightening/cutting/waste collection, adjustable tension via knob, PLC touch screen control, and versatile usage as desktop unit or robot integration.
The HB-C20 requires 110/220VAC, 50/60Hz power (700W) and has dimensions of 650*650*720mm, weighing 130kg. It is a desk-type unit with a handheld gun.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
