PC-C20
| Availability: | |
|---|---|
| Quantity: | |
Wire Coiler – Enhanced Efficiency for Long Wire Processing
The Wire Coiler is specially designed to interface seamlessly with WIREPRO automatic cut and strip machines. It offers a perfect solution for handling long wires without the need for additional collection devices. With its flexible, ergonomic design and user-friendly operation, this machine significantly boosts production efficiency.
As the wire or cable exits the cut and strip machine, it passes through a guide tube into the coiling pan. The coiling pan’s speed synchronizes automatically with the wire or cable feed, ensuring uniform and consistent coil sizes.
Key Features:
1. Seamless Integration: Works perfectly with WIREPRO cut and strip machines.
2. Efficiency Boost: Eliminates the need for additional collection devices.
3. Automatic Synchronization: Ensures uniform-sized coils with synchronized speed adjustment.
4. Ergonomic Design: Easy to use and designed for operator comfort.
5. Enhanced Flexibility: Adapts to various production requirements.
Model | PC-C10 | PC-C20 |
Function | Wire Coiler to coiling wire after cutting and stripping | |
Loading Weight | Max 20kg | Max 32kg |
Coil Inner Dia | 200mm | 200mm |
Coil Outer Dia | Max 380mm | Max 680mm |
Coiling Speed | 1.5 m/s | 1.5 m/s |
Drive Method | Servo motor, adaptive with speed, digital adjustment of speed ratio. | |
Dimension | 53*53*100cm | 85*85*100cm |
Weight | 60kg | 110kg |
Notes: We provide custom service for special cables. | ||
Application
Long wire coiling after stripping.
The PC-C20 is a wire coiler designed to interface with WIREPRO automatic cut and strip machines for handling long wires without additional collection devices, automatically synchronizing speed for uniform coils.
Max loading weight: 32kg. Coil inner diameter: 200mm, outer diameter max 680mm. Coiling speed: 1.5 m/s. Drive: servo motor with digital speed ratio adjustment. Dimensions: 85*85*100cm, weight: 110kg.
PC-C10: 20kg load, max coil OD 380mm, 53*53*100cm, 60kg. PC-C20: 32kg load, max coil OD 680mm, 85*85*100cm, 110kg. Both feature servo drive and 1.5 m/s speed.
Specific power details are not provided on the page. PC-C20 dimensions: 85*85*100cm, weight: 110kg. Requires dedicated floor space. Please contact Wirepro for power specifications.
Standard machines are ready in 3-5 workdays; customized orders require confirmation. The machine is shipped with a manual and video for self-installation. Technical support is available via phone, email, or video. Spare parts are sent via FedEx or DHL for fast delivery.
